LCD Screen Customization:
● Size Available: 0.95inch~15.6inch
● Blacklight Brightness Available: 300nit~2500nit
● Читаемый при солнечном свете опционально
● Interfaces Available: SPI mipi RGB EDP LVDS
● Display Type: IPS/TN
● Operation Temperature: -40~85 degree
● FPC Design Available
Service Support: Software Drive Support, Color gamut Calibration
I. Design experience
Over 11 years experience in outdoor products design, ESD Test through air 25kV, contact 15kV each display, design experience in IK test from IK06 to IK10, and can provide IP68 Waterproof design.
II. Software Debugging
Experience in EFT Surge Immunity Test and Design, SC injection current commissioning.
Headsun can offer the complete service; from design, prototyping, production, certification and support. We have a complete engineering department — with multiple experience engineers. This team brings diverse skills and ideas to your project. We can also review your existing product designs and produce the displays according to your sample.
Competitive price and fast delivery can be guaranteed. Have a question about your LCD screen design project? Contact us now! and we'll create a solution together.
Applications: Charging pile, ATM machine, ship, aviation equipment, on-board industrial control, POS machine. ATM machine, handheld machine, instrument, medical equipment, intelligent monitoring, smart home, household appliances (air conditioner, washing machine, refrigerator, coffee machine, electric rice cooker, range hood)
LCD Display List
NO. | Inch | Resolution | Horizontal/vertical Screen | Display mode | interface | PIN Quantity | brightness CD/M² | A.A size | Module shape size （L*W*T)mm | Other |
1 | 7 | 800*480 | Horizontal Screen | TN | RGB | 50/40 | 300-1500 | 154.08*85.92 | 164*100*2.8 164*100*3.5 164*100*5.5 164*97*2.6 164*103*3.5 164*104*3.5 | |
2 | ||||||||||
3 | ||||||||||
4 | 153.6*86.64 | |||||||||
5 | ||||||||||
6 | ||||||||||
7 | 7 | 1024*600 | Horizontal Screen | TN /IPS | RGB | 50 | 300-1500 | 154.08*85.92 | 164*100*2.8 164*100*3.5 164*100*5.5 164*97*2.6 164*103*3.5 164*104*3.5 | |
8 | ||||||||||
9 | LVDS | 40 | ||||||||
10 | ||||||||||
11 | MIPI | 30/31/33/40/56 | 153.6*86.64 | |||||||
12 | ||||||||||
13 | 7 | 800*1280 | vertical Screen | IPS | MIPI | 31/40 | 400-800 | 94.2*150.72 | 161.0*99.8*2.6 160.9*98.8*2.0 | |
14 | ||||||||||
15 | 6.98 | 720*1280 | vertical Screen | IPS | MIPI | 30/32/40 | 300-500 | 86.94*154.56 | 167*92*2.6 165.9*91.5*2.6 | |
16 | ||||||||||
17 | 6.98 | 540*960 | vertical Screen | TN | MIPI | 30 | 300-500 | 86.94*154.56 | 167*92*2.6 | |
18 | 6.95 | 720*1280 | vertical Screen | IPS | MIPI | 30 | 86.94*154.56 | 163.3*95.0*2.6 | ||
19 | 6.95 | 600*1024 | vertical Screen | IPS | MIPI | 31/45 | 300 | 89.28*152.37 | 163.3*95.0*2.6 | |
20 | 8 | 800*480 | Horizontal Screen | TN | RGB | 50 | 500-1200 | 176.64*99.36 | 192.8*116.9*6.4 | |
21 | 8 | 1024*600 | Horizontal Screen | TN | LVDS | 40 | 500-1200 | 176.64*99.36 | 192.8*116.9*6.4 | |
22 | 8 | 1024*768 | Horizontal Screen | IPS | LVDS | 40 | 500 | 162.048*121.536 | 175.0*136.0*2.8 | |
23 | 8 | 800*600 | Horizontal Screen | TN | RGB | 50 | 500 | |||
24 | 8 | 800*1280 | vertical Screen | IPS | MIPI | 30/31/39/40/45/6 | 240-900 | 107.64*172.224 | 114.6*181.1*2.6 | |
25 | 9 | 800*480 | Horizontal Screen | TN | RGB | 50 | 500-1200 | 198.000*111.696 | 210.7*126.5*3.5 210.7*126.5*5.2 | |
26 | ||||||||||
27 | 9 | 1024*600 | Horizontal Screen | TN /IPS | LVDS | 40/60 | 300-900 | 196.608*114.15 | 210.7*126.4*3.5 210.7*124.6*5.0 | |
28 | RGB | 50 | ||||||||
29 | MIPI | 26/30 | ||||||||
30 | 9.7 | 1024*768 | Horizontal Screen | TN | LVDS | 30 | 400 | 196.61*147.46 | 210.21*150.96*2.9 | |
31 | 10.1 | 1024*600 | Horizontal Screen | TN /IPS | RG | 40/50 | 220-1500 | 125.28*222.72 | 232.72*136.28*2.8 233.7*137.7*2.6 235.0*143.0*2.9 235.0*143.0*4.5 235.0*143.0*5.0 235.0*143.0*3.5 235.0*143.0*2.8 235.0*145.8*5.5 | |
32 | ||||||||||
33 | ||||||||||
34 | LVDS | 40/50/60 | 220-1500 | |||||||
35 | Equal Side | |||||||||
36 | ||||||||||
37 | MIPI | 30/31/40 | ||||||||
38 | ||||||||||
39 | 10.1 | 1280*800 | Horizontal Screen | IPS | LVDS | 30 | 300-500 | 216.96*135.6 | 228.91*148.57*2.65 | |
40 | 10.1 | 800*1280 | vertical Screen | IPS | LVDS | 20/40 | 260-600 | 135.36*216.58 | 143.06*228.66*2.6 143.06*228.66*4.0 | |
41 | MIPI | 31/39/40 | ||||||||
42 | 9.3 | 1024*400 | Horizontal Screen | IPS | RGB | 50 | 300-500 | 222.72*83.52 | 232.72*96.0*2.8 | |
43 | LVDS | 40 | ||||||||
44 | 2.8 | 240*320 | vertical Screen | TN | 8080 | 37 | 400 | 43.2*57.6 | 69.2*50.0*3.5 | |
45 | 4.3 | 480*272 | Horizontal Screen | TN /IPS | RGB | 40 | 300-1500 | 95.04*53.856 | 105.4*67.1*2.9 | |
46 | 4.3 | 800*480 | Horizontal Screen | IPS | RGB | 40 | 300-1500 | 95.04*53.856 | 105.4*67.1*2.9 | |
47 | 5 | 480*272 | Horizontal Screen | TN /IPS | RGB | 40 | 400 | 110.88*62.83 | 120.68*75.84*3.0 | |
48 | 5 | 800*480 | Horizontal Screen | TN /IPS | RGB | 40 | 400 | 108.0*64.8 | 120.68*75.84*3.0 | |
49 | 10.4 | 800*1332 | vertical Screen | IPS | MIPI | 40 | 360 | 135.36*225.3744 | 140.92*234.92*2.6 | |
50 | 10.4 | 1200*2000 | vertical Screen | IPS | MIPI | 45 | 320 | 135.36*225.6 | 153.96*244.2*3.0 | |
51 | 11.6 | 1920*1080 | Horizontal Screen | IPS | EDP | 30 | 300 | 256.32*144.18 | 263.4*157.22*2.6 | |
52 | 13.3 | 1920*1080 | Horizontal Screen | IPS | EDP | 30 | 300 | 293.76*165.24 | 306.2*190.62*2.6 | |
53 | 15.6 | 1366*768 | Horizontal Screen | TN | EDP | 30 | 300 | 344.23*193.54 | 359.5*206.5*3.2 | |
54 | 15.6 | 1920*1080 | Horizontal Screen | IPS | EDP | 30 | 300 | 344.16*193.59 | 350.76*204.96*2.9 | |
55 | 7 | 1024*600 | Horizontal Screen | TN | LVDS | 40 | 300 | 153.6*90.0 | 165.75*105.39*2.8 | |
56 | 7 | 1024*600 | Horizontal Screen | TN | LVDS | 39 | 300 | 153.6*90.0 | 167.25*104.65*2.8 |
Customize other size available, Contact Us for more detail
